Quick Details

  • Condition: New
  • Type: Mini Harvester
  • Usage: Grain Harvester
  • Place of Origin: Zhejiang, China (Mainland)
  • Brand Name: langyuan
  • Model Number: LY-HR430
  • Certificate: CE
  • power source: gasoline/petrol
  • power rating: 2.2kw/6500-7000rpm
  • engine type: Air-cooled, two-stroke, single cylinder
  • color: red orange etc
  • carburetor: diaphragm type

Packaging & Delivery

Packaging Details Packed by colored box or according to customer's requirement
Delivery Time within 15 days after deposit

Two stroke 52cc gasoline paddy cutter mini rice paddy harvester



rice cutter

Notes: The machine needs to add mixed fuel and special two stroke oil is required.

Please use above 90# gasoline.Mixture fuel rating gas : oil = 25:1. Attention :wrong

operation is under warranty.

Packed with two boxes:gasoline and operating rod is singe package.

Applicable scope:plains,hills,terraced field,mud field and so on.It is used for reaping wheat,

rice,bean,bush,reed,highland barley,lucerne etc.

Reap efficiency: 533.3-800 square meters per hour one person,loss ratio<1%.



specification:

Engine Model

1E44F-5

Engine Type

Air-cooled, two-stroke, single cylinder

Engine Power

1.4kw/6500-7000rpm

Engine Displacement

52cc

Carburetor

Diaphragm type

Gasoline/2-cycle Oil mixing ratio

25:1

Working pole length

1650mm

Working pole diameter

24 OR 26 OR 28mm

N.W/G.W

7.2/8.4KG





common sense of using and maintenance:

1.normal safety precautions

1)forbid to use indoor

2)stay away from inflammables at least 1 meter

3)while fueling up ,forbid smoking,stop engine from performing and no fuel to overflow

4)while working,wear protection glasses and protection facilities. Please don't use without protection.

5)hands and feet are away from machine before operating and stoping.

2.Check before operating

1)check fuel level from external fuel tank. If it's low,please fuel up to maximun with gas:oil=25:1

2)check air filter,clean it if there is dirty

3)check throttle cable has free space at the bottom,and whether handle operates smooth and steady.

4)check blade,whether it has flaw or gap,it bends or wears out. Change a new one if needed. Check the

nuts whether they are loose,need to screw nut if loose.

5check cutter guard whether it is loose,screw nuts if needed.check protection guard whether it damaged or not,change it if needed.

3.maintenance

1)take spark plug apart to clean carbon deposit,measure (electrode) gap between 0.6mm-0.7mm

2check fuel filter and clean fuel tank,pour out the fuel,take out the filter then clean it softly,clear away the water the dirt in the fuel tank.

3)check whether the heat sink is dirty through engine hood,clear it if it's dirty

4)check fuel pipe,change it if it is aging or leak oil.

5)change blade in time









Welcome to inquiry! High quality, competitive price and

best service, we are right here waiting for your visit!
